CROWCON – FIXED GAS DETECTION

As part of our Process & Pressure Safety solutions, Teksal Safety supports a range of projects and applications through our Crowcon fixed gas detection products.

Xgard

The Xgard range offers a comprehensive selection of fixed-point gas detectors that meet diverse requirements for flammable and toxic gas detection and oxygen monitoring in industries throughout the world.

Whichever version of the Xgard you choose, you can be confident that they’re designed to operate in even the harshest conditions, and manufactured using materials to withstand these conditions.

DETECTORS FOR OXYGEN, FLAMMABLE AND TOXIC GASES

XGARD BRIGHT

Gas Detection – Fixed Detectors & Control Panels

Xgard Bright offers flammable and toxic gas detection and oxygen monitoring, coupled with reduced installation costs and ease of operation.

Choose from durable sensor options to suit your needs, such as MPS (10+ years), Long-life O2 (5 years) and IR sensors (10+ years) to prevent frequent sensor replacements and minimise operational expenses.

Its addressable operation also reduces the amount of cabling needed for multi-point installations.

XGARDIQ

XGARDIQ gas detector

XgardIQ is an intelligent, versatile, fixed detector and transmitter.

Its remote sensor and universal transmitter means you have access to Crowcon’s full range of sensor technologies and improved detection.

With its sensor range selection capabilities, users can set the full-scale range of the sensor according to location requirements.

Its auto-configure function detects when a sensor module is plugged-in and uploads the appropriate gas type, range, units and alarm levels.

Its Smart Bump and Speedy Bump test functions enable quick sensor-health verification and automated reminders, and its calibration reminders ensure sensors remain operational and accurate at all times.

IRmax

Crowcon IRMax hydrocarbon gas detector

IRmax is a compact, low-power and highly rugged infrared (IR) hydrocarbon gas detector, that delivers rapid, fail-safe detection of methane, butane, propane and many other hydrocarbon gases and vapours.

  • Reliability in all conditions – proven in hot, cold, wet and saline environments
  • Remote, non-intrusive calibration means the remote display can be mounted up to 30 metres from the IRmax, and test gas applied without requiring direct access to the detector
  • Minimal routine maintenance keeps costs down

IR Plus

Crowcon IR Plus

IR Plus is a dual-beam infrared (IR) hydrocarbon detector, designed to ensure safety in the heavy industrial sector by providing real-time, fail-safe detection of methane, propane, and other gases.

Its intelligent heater optics and STAY-CLIR hydrophobic reflectors resist dust, moisture and corrosive chemicals, eliminating false alarms and downtime.

  • Only IR detector of its kind to maintain stability in harsh conditions – no false alarms, reducing down-time Accurate detection of target gases
  • Quickest response time when detecting minimal gas levels (1.0 l/m)
  • Gives you the information you need fast

FGARD RANGE

Crowcon fixed gas detector FGard IR3

Fgard H2

The Fgard H2 is a breakthrough in hydrogen flame detection, delivering first-in-class flame detection with intelligent heated optics for clearer results, and advanced optical verification to greatly reduce false alarms.

Fgard IR3

Fgard IR3 flame detector is an explosion-proof, multi-spectrum infrared (IR) flame detector, responding to hydrocarbon liquid fuel and gas fires even at long distances.

It delivers first-in-class flame detection, with intelligent heated optics for clearer results and advanced optical verification to greatly reduce false alarms.

Fgard UVIR

Fgard UVIR flame detector is an explosion-proof ultraviolet-infrared flame detector, offering superior detection of hydrocarbon fires that are not detectable in the visible spectrum.

With adjustable sensors, the Fgard UVIR can be adapted to suit your space, and is capable of operating in even the harshest conditions.

Each model of the Fgard has intelligent heated optics, which means no risk of condensation, ice or water on the lens for unimpaired performance in all weather.

Control Panels

Gasmaster

Crowcon Gasmaster controller

Gasmaster is a compact, versatile and powerful gas detection control panel that combines simple operation with an extensive array of input and output functions.

The large multi-lingual display shows gas levels from all detectors simultaneously, with a user friendly, intuitive menu system, making system adjustment and testing using buttons on the front panel straightforward.

  • Event log feature allows system fault and alarm history to be viewed
  • Input and output features provide analogue, relay and Modbus outputs to suit your site’s communication needs
  • Can monitor up to four detectors in virtually any combination of gas detectors, fire zones or Environmental Sampling Units
  • Compatible with a 4-20mA or mV pellistor-type gas detector, providing ways to reduce system purchase and maintenance costs

GM Controllers

Crowcon GM addressable controller

User friendly and easy to configure, these Crowcon addressable gas detection controllers offer a live feed of communication and a variety of data insights.

Each has different channel input variables, is modular, and can be configured to your requirements:

  • GM16: 1-16 channel inputs
  • GM64: 1-64 channel inputs
  • GM128: 1-128 channel inputs

All are available as 19” rack-mounted, with enclosure options available for GM16 & GM64.

They only include what is needed for the application, reducing complexity and cost.

As the channels can be grouped into zoned areas, data can be viewed in a variety of ways to provide comprehensive insight into the safety of your site.

From 3-minuite trends of one channel to an analysis of up to 16 channels at a time, with direct to web page live feed communication for remote viewing, you can be confident you have full visibility and control of your environment at all times.

VORTEX

Crowcon Vortex controller

Even for large, complex sites with a variety of detection needs, the Crowcon Vortex provides streamlined management of up to 12 devices, including three for fire, making it easy to have full visibility and control of your site.

Each channel has one fault level and three alarm levels, which can be combined in any pattern to trigger up to 32 output relays.

Designed with flexibility in mind, while the Vortex will initially be configured to suit your operational needs, channels and alarms can be easily customised, if requirements change.

  • Modbus compatibility with no extensive cabling required
  • Internal battery pack* means you’re protected even during power outage
  • LED display panel lights mean faults are easily seen and the whole system can be checked at a glance

Other standard features include RS-485 Modbus communications for remote non-intrusive calibration and configuration.

internal-call-to-action

Interested in these products?

For more information about these products or any of our industrial safety solutions and services, call 1300 TEKSAL or email sales@teksal.com.au
